This guide walks you through Option 2 (Local Install) of the Cloudera Iceberg MCP Server on a local machine. The Iceberg MCP Server is a Model Context Protocol (MCP) server that gives LLMs and AI agents read-only access to Iceberg tables via Apache Impala. It exposes two powerful tools:

  • get_schema() – Lists all tables available in the current database.
  • execute_query(query: str) – Runs any SQL query on Impala and returns results as JSON.

This setup is tested against a Cloudera Public Cloud (CDP) on AWS environment and confirmed to work perfectly with MCP Inspector.

The instructions mirror the style and detail of my previous guide: How To Install Cloudera NiFi MCP Server.

Prerequisites

Before you begin, make sure you have the following on your Mac:

  1. Git – brew install git (or already installed via Xcode Command Line Tools).
  2. Node.js – Required for npx and MCP Inspector. Install with:
    brew install node
  3. uv – Modern Python package manager (used by the Iceberg MCP Server). Install with:
    curl -LsSf https://astral.sh/uv/install.sh | sh

    Then restart your terminal or run source $HOME/.cargo/env.

  4. Cloudera Public Cloud (AWS) access – You need Impala connection details (see next section).

Step 1: Obtain Impala Connection Details from Cloudera Public Cloud on AWS

The MCP Server connects to your Impala Virtual Warehouse (or Data Hub cluster with Impala) in CDP Public Cloud on AWS. Connection is via the Knox gateway (HTTPS, port 443).

How to get the details:

  1. Log in to the Cloudera Management Console → Data Warehouse service.
  2. Select your Virtual Warehouse (Impala type).
  3. In the Details tab or Connection section, click Copy JDBC URL (or find the Impala coordinator endpoint).
  4. The JDBC URL will look similar to this:
    jdbc:impala://coordinator-default-impala-aws.[dw name].[env name].cloudera.site:443/default;AuthMech=12;transportMode=http;httpPath=cliservice;ssl=1;auth=browser
  5. Extract these values for the MCP Server environment variables:
    • IMPALA_HOST → coordinator-default-impala-aws.[dw name].[env name].cloudera.site (the hostname only)
    • IMPALA_PORT → 443
    • IMPALA_USER → Your workload username (e.g., srv_cia_test_user or IAM user)
    • IMPALA_PASSWORD → The corresponding password
    • IMPALA_DATABASE → Usually default (or your target database)

Tip: Use a workload user or service account with appropriate Impala permissions.

Step 2: Clone the Repository

git clone https://github.com/cldr-steven-matison/iceberg-mcp-server.git
cd iceberg-mcp-server

Step 3: Set Environment Variables

Create a .env file in the root of the repository for easy loading (recommended):

cat > .env << EOF
IMPALA_HOST=coordinator-default-impala-aws.[dw name].[env name].cloudera.site
IMPALA_PORT=443
IMPALA_USER=yourworkloaduser
IMPALA_PASSWORD=yourpassword
IMPALA_DATABASE=default
# Optional: Change transport if needed (default is stdio)
# MCP_TRANSPORT=stdio
EOF

Load the variables in your current terminal session:

set -a; source .env; set +a

Step 4: Run the MCP Server with MCP Inspector

MCP Inspector is the easiest way to test the server locally.

npx @modelcontextprotocol/inspector uv run src/iceberg_mcp_server/server.py

This command:

  • Opens the MCP Inspector in your browser.
  • Launches the Iceberg MCP Server locally using uv.

Step 5: Testing – Confirmation Iceberg MCP Services Work with MCP Inspector

Once the MCP inspector loads:

  1. Connect to the server (it auto-detects the running process).
  2. Confirm the server version and status.
  3. List Tools – You should see:
    • get_schema()
    • execute_query(query: str)

Example Tests

Test 1: Get Schema

Click Run Tool

→ Returns a JSON list of all tables in the IMPALA_DATABASE.

Test 2: Execute a Simple Query

SHOW TABLES Click Run Tool

→ Returns table names as JSON.

Test 3: Real Iceberg Query

SELECT * FROM your_iceberg_table LIMIT 5 Click Run Tool

→ Returns actual data rows.

Success

All tests complete without errors, tools are listed correctly, and queries return valid JSON results from your Cloudera Public Cloud Impala/Iceberg environment. The server is ready for use with Claude Desktop, LangChain, or any MCP client.

Cloudera MCP Servers

How To Install Cloudera Iceberg MCP Server

If you would like a deeper dive, hands on experience, demos, or are interested in speaking with me further about How To Install Cloudera Iceberg MCP Server please reach out to schedule a discussion.

Appendix

1. Contributing Back – Example PR from Develop Branch

The goal of this exercise post installation — is to teach how to contribute back to the upstream Cloudera project.

Suggested Contribution (Easy Starter PR)

Item/Adjustment: Add more local-install instructions + .env support to the README.

Why this is valuable:

  • The current upstream README (cloudera/iceberg-mcp-server) only has minimal Option 2 instructions.

How to Contribute (Step-by-Step)

  1. In your fork (cldr-steven-matison/iceberg-mcp-server):
    git checkout -b develop
git push -u origin develop
  2. Make the change (example):
    • Update README.md with the steps you just followed.
  3. Commit and push:
    git add README.md
git commit -m "feat: update readme local install"
git push
  4. Open a Pull Request:
    • Go to your fork on GitHub → Compare & pull request → Base repository: cloudera/iceberg-mcp-server → Base branch: main
    • Title: “Update Readme for Local Install”
    • Link back to this blog post for context.

This PR would be merged quickly because it improves documentation for the entire community.
