Cloudera Flow Management (CFM) Operator makes it easy to stand up an Apache NiFi cluster on Kubernetes with a single Nifi custom resource. What isn’t obvious the first time you deploy it is that a “working” install still loses state in five different places the moment a pod restarts, plus a sixth surface — Python extensions — that most people patch with a minikube mount and then quietly curse every time the mount dies.

This post walks through fixing all of them in one pass, using the same cfm-streaming minikube cluster the rest of my Cloudera Streaming Operators (CSO) demos run in. Everything here is validated against CFM Operator 3.2.0-b39 with NiFi 2.6.0 on minikube v1.37.0 / k8s v1.34.0.

Companion post covering the same thing for SQL Stream Builder + Flink under the CSA Operator: Persistence with Cloudera Streaming Analytics Operator.

What CFM actually stores, and where

Before touching any YAML, this is the layout you’re aiming for:

State Where the operator puts it Path in pod Persisted by
flow.xml.gz, authorizers.xml, users, state.xml data repo /opt/nifi/nifi-current/data PVC per pod via spec.persistence.data
In-flight FlowFiles flowfileRepo /opt/nifi/nifi-current/flowfile-repository PVC per pod via spec.persistence.flowfileRepo
Payload content contentRepo /opt/nifi/nifi-current/content-repository PVC per pod via spec.persistence.contentRepo
Provenance / lineage provenanceRepo /opt/nifi/nifi-current/provenance-repository PVC per pod via spec.persistence.provenanceRepo
Node runtime state, leader election state /opt/nifi/nifi-current/state PVC per pod via spec.persistence.state
Custom Java NARs narProvider /opt/nifi/nifi-current/nar-provider (Cloudera-specific) Shared PVC via spec.narProvider.volumes
Python extensions (processors) statefulset.volumes /opt/nifi/nifi-current/python/extensions Shared PVC via spec.statefulset.volumes

Rows 1–5 come from NifiPersistenceSpec (documented in the CFM Operator Helm/CR reference). Rows 6 and 7 need extra care — row 7 in particular is where the “minikube mount” trap sits.

The good news: the operator already knows how to manage all of this via volumeClaimTemplates on the underlying StatefulSet. You just need to declare the storage in the right places on the Nifi CR.

Prerequisites

  • StorageClass that supports ReadWriteOnce (RWO) — this is what minikube’s standard class gives you, and what almost every cloud provisioner (gp3, standard, longhorn, openebs, etc.) defaults to. RWO is fine for repos and state (they’re per-pod). Custom NARs / Python extensions need RWX if you scale NiFi beyond a single node — more on that below.
  • CFM Operator installed in the same namespace as (or a namespace that watches) the target Nifi CR.
  • CFM Operator version 3.2.0-b39 for this walkthrough — the images are:
    • container.repository.cloudera.com/cloudera/cfm-operator:3.2.0-b39
    • container.repository.cloudera.com/cloudera/cfm-nifi-k8s:3.1.0-b129-nifi_2.6.0.4.12.0.1-9 (NiFi 2.x)
    • container.repository.cloudera.com/cloudera/cfm-tini:3.2.0-b39

Important notes before starting:

  • PVCs created by volumeClaimTemplates are per-pod (named like <name>-<repo>-<ordinal>, e.g. data-mynifi-0). They are not deleted when you update the CR or roll the pod. That’s what makes this work — the operator hands the same PVC back to the new pod after a restart.
  • Operator handles data offloading during scale-down automatically.
  • No changes to nifi.properties or ConfigMaps needed — the operator injects the mounts.
  • Tested / validated pattern against CFM Operator 3.2.

Step 1 — Prepare your StorageClass

Confirm your default StorageClass works, or create a named one so you can point specific repos at it:

kubectl get storageclass
kubectl describe storageclass <your-storageclass-name>

Look for the provisioner — on minikube it’s k8s.io/minikube-hostpath; yours may be different. If you want a dedicated class for NiFi repos, save this as nifi-storage-class.yaml:

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: nifi-storage
provisioner: k8s.io/minikube-hostpath
reclaimPolicy: Retain
volumeBindingMode: Immediate
allowVolumeExpansion: true

allowVolumeExpansion: true matters — you’ll thank yourself the day the content repo fills up and you want to bump it without redeploying NiFi.

kubectl apply -f nifi-storage-class.yaml

Export your current Nifi CR for backup and diffing before touching anything:

kubectl get nifi mynifi -n cfm-streaming -o yaml > nifi-base-backup.yaml

Step 2 — Persist the five NiFi repos (spec.persistence)

Edit your Nifi CR file (mine is nifi-cluster-30-nifi2x-python.yaml, yours might be named differently). Add — or expand — the persistence block under spec:, at the same level as replicas, image, security, etc.

Recommended minimal configuration for flows + good durability:

spec:
  # ... your existing settings (replicas, image, etc.) ...

  persistence:
    # Global defaults (applied to any repo not explicitly overridden)
    size: 10Gi
    storageClass: nifi-storage

    # === CRITICAL FOR FLOWS ===
    data:                     # ← persists flow.xml.gz + configs
      size: 20Gi              # bump if you have large / complex flows
      storageClass: nifi-storage

    # Highly recommended companions
    state:                    # node runtime state, leader election, etc.
      size: 5Gi
      storageClass: nifi-storage

    flowfileRepo:             # in-flight FlowFiles
      size: 20Gi
      storageClass: nifi-storage

    contentRepo:              # actual payload content
      size: 50Gi              # often the largest
      storageClass: nifi-storage

    provenanceRepo:           # lineage / audit data
      size: 30Gi
      storageClass: nifi-storage

Why the data repo is the one to focus on: the base / evaluation Nifi CRs you’ll see in Cloudera samples (or the pattern in nifi-cluster-30-nifi2x-python.yaml before this change) often omit full persistence or use ephemeral storage for simplicity. That causes flow loss on StatefulSet re-rolls — the single most annoying failure mode in this whole stack. The data repo is what stores flow.xml.gz, so persisting it is the direct fix. Everything else (state, flowfile, content, provenance) is durability for FlowFiles in-flight and lineage records — set them too if you care about surviving a re-roll mid-run.

Step 3 — Delete and re-apply the CR

If NiFi is already deployed on the ephemeral StatefulSet, delete it. This is the last time you have to re-create your flows. Once persistence is in place, the same PVCs will get handed back to every future pod.

kubectl delete nifi mynifi -n cfm-streaming
kubectl apply -f nifi-cluster-30-nifi2x-python.yaml -n cfm-streaming

The operator will re-roll NiFi and new PVCs will be created automatically. Watch:

kubectl get pods -n cfm-streaming -l app.kubernetes.io/name=nifi -w
kubectl get pvc  -n cfm-streaming -w

You should see PVCs like this appear and go Bound:

NAME                             STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   AGE
content-repository-mynifi-0      Bound    pvc-ed5daf31-...                           50Gi       RWO            nifi-storage   3m
data-mynifi-0                    Bound    pvc-d6054f5e-...                           20Gi       RWO            nifi-storage   3m
flowfile-repository-mynifi-0     Bound    pvc-ea2041f6-...                           20Gi       RWO            nifi-storage   3m
provenance-repository-mynifi-0   Bound    pvc-8fc752e8-...                           30Gi       RWO            nifi-storage   3m
state-mynifi-0                   Bound    pvc-37bdae77-...                           5Gi        RWO            nifi-storage   3m

That output is copy-pasted from this laptop’s actual cfm-streaming namespace — this is what a working install looks like.

Step 4 — Prove flow persistence works

The real test — deploy a flow, force a re-roll, confirm the flow’s still there:

  1. Open the NiFi UI, build a small flow, start it, confirm it runs.

  2. Force a re-roll (this is the safest way, it re-schedules the pod without deleting the CR):

     kubectl rollout restart statefulset mynifi -n cfm-streaming

  3. Wait for the pod to be Running / Ready again:

     kubectl rollout status statefulset/mynifi -n cfm-streaming --timeout=180s
  4. Refresh the NiFi UI — your test flow must still be there.

If it’s not, check the pod’s mounts and PVC bindings:

kubectl exec -n cfm-streaming mynifi-0 -c nifi -- mount | grep nifi-current
kubectl describe pod -n cfm-streaming mynifi-0 | grep -A2 -iE "flowfile|content|provenance|state|data"
kubectl logs -n cfm-streaming mynifi-0 -c nifi | grep -i persist

Step 5 — Persist custom Java NARs (narProvider)

CFM Operator has a first-class field for custom NARs — you don’t have to wire this into the StatefulSet by hand. Add a narProvider block to spec::

spec:
  # ... persistence block from step 2 ...
  narProvider:
    volumes:
      - volumeClaimName: custom-nars

And create the PVC once, ahead of the CR apply:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: custom-nars
  namespace: cfm-streaming
spec:
  storageClassName: "standard"
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 100Mi

Drop your .nar files into it — the simplest way is a one-shot loader pod, same pattern as Step 6 below. Once they’re on the PVC, the operator mounts them into every NiFi pod under /opt/nifi/nifi-current/nar-provider/<pvc-name>/ (in this example, /opt/nifi/nifi-current/nar-provider/custom-nars/) and NiFi picks up the components on the next restart. The subdirectory is named after the PVC, which matters if you’re wiring up multiple NAR sources.

Confirm the PVC has what you expect:

kubectl run tmp-inspect --rm -it --restart=Never --image=busybox -n cfm-streaming \
  --overrides='{"spec":{"containers":[{"name":"tmp-inspect","image":"busybox","command":["ls","-la","/mnt/nars"],
    "volumeMounts":[{"name":"n","mountPath":"/mnt/nars"}]}],
    "volumes":[{"name":"n","persistentVolumeClaim":{"claimName":"custom-nars"}}]}}'

Output on this laptop:

total 136
-rw-r--r-- 1 501 staff   1957 Apr  8 17:22 custom-transaction-generator.nar
-rw-r--r-- 1 501 staff 126892 Apr  9 12:57 nifi-mycustom-nar-1.0.0-SNAPSHOT.nar

If you scale NiFi to more than one node, swap the StorageClass for an RWX one (Longhorn, NFS, cloud file-share). RWO is fine for a single-node minikube demo.

Step 6 — Persist Python extensions (moving off the minikube mount trap)

This is the piece the current cfm-persisted-volume.md didn’t cover, and the piece I’ve been fighting the longest.

The trap

When you first stand up NiFi 2.x with custom Python processors on minikube, the natural thing to do is drop them onto a folder on your Mac and mount it into the minikube VM:

minikube mount ~/nifi-custom-processors:/extensions &

…and reference /extensions from the Nifi CR as a hostPath:

spec:
  statefulset:
    volumes:
      - name: python-extensions
        hostPath:
          path: /extensions
    volumeMounts:
      - name: python-extensions
        mountPath: /opt/nifi/nifi-current/python/extensions

This works. It’s also fragile:

  • minikube mount runs a 9p filesystem over the minikube network. Inspecting mount inside the NiFi pod shows exactly that: 192.168.65.254 on /opt/nifi/nifi-current/python/extensions type 9p (rw,relatime,dfltuid=10001,dfltgid=10001,...). That’s a network mount, not real storage.
  • The 9p connection dies on minikube stop / start, on network flaps, and every time the mount command’s background process is killed. When it dies, NiFi’s Python processors go missing — sometimes with Could not load module, sometimes silently.
  • It only works because the developer running the demo remembered to run minikube mount. Nothing in the cluster references it or restarts it.
  • It doesn’t survive being moved to any real cluster — there is no /extensions on your production nodes.

The fix — a real PVC, seeded by a loader pod

Save this as python-extensions-loader.yaml:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: custom-python-extensions
  namespace: cfm-streaming
spec:
  storageClassName: "standard"
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 100Mi
---
apiVersion: v1
kind: Pod
metadata:
  name: python-extensions-loader
  namespace: cfm-streaming
spec:
  containers:
    - name: ubuntu
      image: ubuntu:latest
      command: ["/bin/bash"]
      stdin: true
      tty: true
      volumeMounts:
        - name: custom-python-extensions-vol
          mountPath: /home/ubuntu/extensions
  volumes:
    - name: custom-python-extensions-vol
      persistentVolumeClaim:
        claimName: custom-python-extensions

Apply, then copy your Python processors in:

kubectl apply -f python-extensions-loader.yaml -n cfm-streaming
kubectl wait --for=condition=Ready pod/python-extensions-loader -n cfm-streaming --timeout=60s

# Copy your extensions folder into the PVC via the loader pod
kubectl cp ~/nifi-custom-processors/. \
  cfm-streaming/python-extensions-loader:/home/ubuntu/extensions/

# Sanity check
kubectl exec -n cfm-streaming python-extensions-loader -- ls -la /home/ubuntu/extensions/

Then — and this bit isn’t optional — fix ownership so NiFi’s non-root user (uid 10001) can read and write. kubectl cp from macOS drops files owned by the source-machine’s UID (typically 501:staff), which the pod then can’t touch:

kubectl exec -n cfm-streaming python-extensions-loader -- \
  chown -R 10001:10001 /home/ubuntu/extensions/

Skip this and NiFi silently fails to load the module — with logs that only tell you “Could not load module” and no chmod hint.

The loader stays running so you can kubectl cp more files in later without re-applying anything. Delete it when you’re done editing extensions:

kubectl delete pod python-extensions-loader -n cfm-streaming

The PVC and its contents stay behind — that’s the whole point.

Point NiFi at the PVC instead of /extensions

Update the Nifi CR’s statefulset.volumes block: swap the hostPath for the PVC. This is the diff, in place:

spec:
  statefulset:
    volumes:
      - name: python-extensions
        persistentVolumeClaim:
          claimName: custom-python-extensions      # ← was: hostPath.path: /extensions
    volumeMounts:
      - name: python-extensions
        mountPath: /opt/nifi/nifi-current/python/extensions

Re-apply the CR and roll. The full CR YAML that pairs with this walkthrough lives in cldr-steven-matison/ClouderaStreamingOperators as nifi-cluster-32-nifi2x-pvc.yaml:

kubectl apply -f nifi-cluster-32-nifi2x-pvc.yaml -n cfm-streaming
kubectl rollout restart statefulset mynifi -n cfm-streaming
kubectl rollout status  statefulset/mynifi -n cfm-streaming --timeout=180s

Tip: run kubectl diff -f nifi-cluster-32-nifi2x-pvc.yaml first. If your live NiFi is healthy and only /extensions needs to change, the diff should be a single volume replacement — nothing else. If you see repo PVCs, images, or security blocks moving, stop and reconcile the YAML with the live CR before applying.

You can also kill the minikube mount process now — nothing needs it anymore.

Verify inside the pod that the extensions path is a real block device (backed by the PVC) instead of a 9p network mount:

kubectl exec -n cfm-streaming mynifi-0 -c nifi -- mount | grep 'python/extensions'
# Expect: /dev/... on /opt/nifi/nifi-current/python/extensions type ext4 (rw,relatime,discard)
# NOT:    192.168.65.254 on /opt/nifi/nifi-current/python/extensions type 9p ...

That’s the signal — real disk, not a fragile mount.

Multi-node caveat: just like custom NARs, if you scale NiFi beyond one pod, custom-python-extensions must be on an RWX StorageClass (Longhorn, NFS, cloud file-share). RWO works fine on single-node minikube.

Full CR — put it all together

For copy-paste, this is a complete nifi-cluster-32-nifi2x-pvc.yaml covering steps 2–6 — the same file lives in cldr-steven-matison/ClouderaStreamingOperators alongside python-extensions-loader.yaml:

apiVersion: cfm.cloudera.com/v1alpha1
kind: Nifi
metadata:
  name: mynifi
  namespace: cfm-streaming
spec:
  replicas: 1
  nifiVersion: "2.6.0"
  image:
    repository: container.repository.cloudera.com/cloudera/cfm-nifi-k8s
    tag: 3.1.0-b129-nifi_2.6.0.4.12.0.1-9
    pullSecret: cloudera-creds
  tiniImage:
    repository: container.repository.cloudera.com/cloudera/cfm-tini
    tag: 3.2.0-b39
    pullSecret: cloudera-creds

  # === Step 2 — five NiFi repos ===
  persistence:
    size: 10Gi
    storageClass: nifi-storage
    data:           { size: 20Gi, storageClass: nifi-storage }
    state:          { size:  5Gi, storageClass: nifi-storage }
    flowfileRepo:   { size: 20Gi, storageClass: nifi-storage }
    contentRepo:    { size: 50Gi, storageClass: nifi-storage }
    provenanceRepo: { size: 30Gi, storageClass: nifi-storage }

  # === Step 5 — custom Java NARs ===
  narProvider:
    volumes:
      - volumeClaimName: custom-nars

  # === Step 6 — Python extensions on a PVC (not a minikube mount) ===
  statefulset:
    volumes:
      - name: python-extensions
        persistentVolumeClaim:
          claimName: custom-python-extensions
    volumeMounts:
      - name: python-extensions
        mountPath: /opt/nifi/nifi-current/python/extensions

  hostName: mynifi-web.mynifi.cfm-streaming.svc.cluster.local
  uiConnection:
    type: Ingress
    ingressConfig:
      hostname: ""
    annotations:
      nginx.ingress.kubernetes.io/affinity: cookie
      nginx.ingress.kubernetes.io/affinity-mode: persistent
      nginx.ingress.kubernetes.io/backend-protocol: HTTPS
      nginx.ingress.kubernetes.io/ssl-passthrough: "true"
      nginx.ingress.kubernetes.io/ssl-redirect: "true"
  security:
    initialAdminIdentity: "admin"
    nodeCertGen:
      issuerRef:
        name: cfm-operator-ca-issuer-signed
        kind: ClusterIssuer
    singleUserAuth:
      enabled: true
      credentialsSecretName: "nifi-admin-creds"
  configOverride:
    nifiProperties:
      upsert:
        nifi.cluster.leader.election.implementation: "KubernetesLeaderElectionManager"
  stateManagement:
    clusterProvider:
      id: kubernetes-provider
      class: org.apache.nifi.kubernetes.state.provider.KubernetesConfigMapStateProvider

The full persistence test

Bounce NiFi and confirm every piece of state survives:

# 1. Baseline
kubectl exec -n cfm-streaming mynifi-0 -c nifi -- \
  ls /opt/nifi/nifi-current/data /opt/nifi/nifi-current/python/extensions

# 2. Roll the StatefulSet
kubectl rollout restart statefulset/mynifi -n cfm-streaming
kubectl rollout status  statefulset/mynifi -n cfm-streaming --timeout=180s

# 3. Same files? Flow still visible in the UI?
kubectl exec -n cfm-streaming mynifi-0 -c nifi -- \
  ls /opt/nifi/nifi-current/data /opt/nifi/nifi-current/python/extensions

# 4. Every mount is a real block device, no 9p, no emptyDir
kubectl exec -n cfm-streaming mynifi-0 -c nifi -- mount | \
  grep -E 'nifi-current|nar-provider'

Refresh the NiFi UI — every flow, every custom Java NAR, every Python processor should be exactly where you left it.

Failure modes I’ve hit

Symptom Cause Fix
Flow disappears after a StatefulSet re-roll data repo not persisted (ephemeral or emptyDir) Step 2 — add spec.persistence.data
Could not load module on Python processors after minikube stop / start The minikube mount 9p filesystem died with the VM Step 6 — move to a PVC
Python processors work locally but the same CR fails on a “real” cluster hostPath: /extensions doesn’t exist on those nodes Step 6 — the PVC pattern works everywhere
Custom NAR appears in custom-nars PVC but NiFi UI doesn’t show the processor narProvider block missing from the CR (or the operator hasn’t rolled) Step 5, then kubectl rollout restart statefulset/mynifi
PVCs stuck Pending — no volume plugin matched StorageClass name typo, or default class not set on the cluster kubectl get storageclass; check spelling and default annotation
Content repo fills up mid-demo and the pod goes OOMKilled-adjacent contentRepo too small With allowVolumeExpansion: true on the class, kubectl edit pvc content-repository-mynifi-0, bump spec.resources.requests.storage
helm uninstall on the operator wipes NiFi state It shouldn’t — the PVCs are labelled to survive, but confirm kubectl get pvc -n cfm-streaming after uninstall; they should still be Bound
Scaling NiFi to replicas: 2+ fails to schedule the second pod custom-nars / custom-python-extensions on an RWO class Move both to an RWX StorageClass (Longhorn, NFS, cloud file-share)

Expected outcome

After all six steps, this is what you get:

  • Flows survive kubectl rollout restart, minikube stop / start, node failures, and CFM Operator upgrades.
  • In-flight FlowFiles and content survive the same events — no data loss mid-pipeline.
  • Provenance history is preserved across restarts, so lineage queries still return real answers after a bounce.
  • Custom Java NARs and Python processors are cluster-native — no hostPath, no minikube mount, no manual re-syncing. The same YAML that works on your laptop works on a real cluster.
  • /extensions is no longer a minikube trap. It’s a first-class PVC with a documented loader-pod pattern for adding new processors.

That last one is the big win. It’s the difference between a demo that works on the presenter’s laptop and a recipe you can ship.

Reference

Everything in this post was validated against CFM Operator 3.2.0-b39 on minikube v1.37.0 / k8s v1.34.0, with NiFi 2.6.0. The CFM Operator installs into cfm-streaming and manages the mynifi Nifi CR referenced throughout.

Cloudera Flow Management (CFM)

Companion persistence posts (same cld-streaming / cfm-streaming cluster)

The rest of the Cloudera Streaming Operators family (CSO)

Repos and images

  • Helm chart (OCI): oci://container.repository.cloudera.com/cloudera-helm/cfm-operator/cfm-operator
  • Container images (validated against CFM Operator 3.2.0-b39):
    • container.repository.cloudera.com/cloudera/cfm-operator:3.2.0-b39
    • container.repository.cloudera.com/cloudera/cfm-tini:3.2.0-b39
    • container.repository.cloudera.com/cloudera/cfm-nifi-k8s:3.1.0-b129-nifi_2.6.0.4.12.0.1-9 (NiFi 2.x)
    • container.repository.cloudera.com/cloudera/cfm-nifi-k8s:3.1.0-b129-nifi_1.28.1.2.3.17.0-9 (NiFi 1.x)
    • container.repository.cloudera.com/cloudera/cfm-nifiregistry-k8s:3.1.0-b129-nifi_2.6.0.4.12.0.1-9 (Registry, NiFi 2.x)
  • Sample YAMLs and helm values I use across the CSO stack: cldr-steven-matison/ClouderaStreamingOperators

Persistence with Cloudera Flow Management Operator

If you would like a deeper dive, hands on experience, demos, or are interested in speaking with me further about Persistence with Cloudera Flow Management Operator please reach out to schedule a discussion.

You may also enjoy
