CSA on Kubernetes is easy to install with the Cloudera Helm chart. What’s not so obvious the first time you deploy it is that a “working” install still loses state in three separate places the moment a pod restarts:

  1. SSB metadata (materialized view definitions, projects, connectors, jobs) lives in Postgres — the chart already creates a PVC for that, but only 100 Mi and only if you leave ssb.database.create=true.
  2. User artifacts (Iceberg JAR, custom UDF JARs, Python UDFs, anything you upload from the SSB UI) — by default there is no persistent volume mounted at /persistent, so uploads fail with Mkdirs failed to create file... and even when they don’t, they disappear on the next re-roll.
  3. Flink job state — checkpoints, savepoints, HA metadata. Without a durable state.checkpoints.dir and high-availability.storageDir, a Flink job restart loses exactly-once guarantees and any keyed state you built up.

This post walks through fixing all three, in order, using the same cld-streaming minikube cluster the rest of my CSA demos run in. Everything here is CSA Operator 1.5.0-b275 on minikube v1.37.0 / k8s v1.34.0.

Companion post covering Schema Registry on the same Postgres pod: Persisting Schema Registry with PostgreSQL. Companion post covering the same thing for NiFi under the CFM Operator: Persistence with Cloudera Flow Management Operator.

What CSA actually stores, and where

Before touching any YAML, this is the layout you’re aiming for:

State Backing store Path in pod Helm value / Flink key
SSB metadata (projects, MV defs, users, jobs) Postgres ssb_admin DB in ssb-postgresql /var/lib/postgresql/data ssb.database.pvcSpec.resources.requests.storage
Uploaded artifacts (JARs, Python UDFs) PVC ssb-artifacts-pvc /persistent (SSE) + optional Flink mount ssb.storageConfiguration + podVolumes / podVolumeMounts
Flink checkpoints S3 / HDFS / PVC state.checkpoints.dir flink-conf.yaml → state.checkpoints.dir
Flink savepoints S3 / HDFS / PVC state.savepoints.dir flink-conf.yaml → state.savepoints.dir
Flink HA metadata (JobManager leader, JobGraph) S3 / HDFS / PVC high-availability.storageDir flink-conf.yaml → high-availability.*
Schema Registry schemas Postgres registry DB in same ssb-postgresql — See companion post

The default helm install gets you row 1 (100 Mi). Rows 2–5 are on you.

Phase 1 — Persist SSB Metadata (Postgres)

The chart already provisions this, but 100 Mi runs out fast the moment you register a handful of connectors and start jobs. Bump it before you deploy — resizing a PVC after the fact requires allowVolumeExpansion: true on the StorageClass and a rollout.

Option A — set at install time via a values file. Add this to your csa-values.yaml:

ssb:
  database:
    create: true
    pvcSpec:
      accessModes:
        - ReadWriteOnce
      resources:
        requests:
          storage: 5Gi        # was 100Mi
      # storageClassName: nifi-storage   # optional, if you want a specific class
    resources:
      limits:
        cpu: "1"
        memory: "2048Mi"      # bumped from 1Gi
      requests:
        cpu: "500m"
        memory: "1024Mi"

Then install (or upgrade) with -f csa-values.yaml.

Option B — you already installed CSA and just need to prove it’s persisted. Verify the PVC is bound and points at real storage, not emptyDir:

kubectl get pvc -n cld-streaming ssb-postgresql-db
kubectl exec -n cld-streaming deploy/ssb-postgresql -- \
  mount | grep /var/lib/postgresql/data

You should see a real block device on /var/lib/postgresql/data, not tmpfs.

Persistence test:

kubectl rollout restart deployment/ssb-postgresql -n cld-streaming
kubectl rollout status  deployment/ssb-postgresql -n cld-streaming --timeout=180s
# SSB UI → your projects, connectors, MV definitions should all still be there.

If they’re gone, ssb-postgresql-db is not actually bound to real storage — check its STATUS and STORAGECLASS.

Phase 2 — Persist SSB User Artifacts (/persistent)

This is the piece that bit me first: uploading the Iceberg JAR from the SSB UI failed with Mkdirs failed to create file:/persistent/global/tmp/.... The path doesn’t exist inside the SSE pod at all — the chart never mounts it.

The fix is to create a PV/PVC, mount it into ssb-sse at /persistent, open permissions so the ssb user can write, and tell SSB that’s where artifacts go.

Step 2.1 — Create the PV and PVC

For minikube (hostPath is fine; for a real cluster use your StorageClass), save this as ssb-storage.yaml:

apiVersion: v1
kind: PersistentVolume
metadata:
  name: ssb-pv
spec:
  capacity:
    storage: 5Gi
  accessModes:
    - ReadWriteOnce
  hostPath:
    path: "/data/ssb-persistent"
---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: ssb-artifacts-pvc
  namespace: cld-streaming
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 5Gi

Apply:

kubectl apply -f ssb-storage.yaml

Step 2.2 — Attach the volume to ssb-sse

The clean way is to add it via Helm (ssb.podVolumes + ssb.podVolumeMounts — the same knobs the chart uses to mount Hadoop config or custom truststores), because those mounts are then applied to both SSB and every Flink pod SSB spins up. That matters when a Flink job needs to read the JAR you uploaded.

Add to csa-values.yaml:

ssb:
  podVolumes:
    create: true
    data:
      - name: persistent-storage
        persistentVolumeClaim:
          claimName: ssb-artifacts-pvc
  podVolumeMounts:
    create: true
    data:
      - name: persistent-storage
        mountPath: /persistent

Then helm upgrade to apply.

If you already installed CSA and just want to patch the running deployment (works, but only mounts on ssb-sse, not on Flink pods — fine for the upload path, not fine for jobs that need the artifact at runtime):

kubectl patch deployment ssb-sse -n cld-streaming --patch '
{
  "spec": {
    "template": {
      "spec": {
        "containers": [
          {
            "name": "ssb-sse",
            "volumeMounts": [
              { "name": "persistent-storage", "mountPath": "/persistent" }
            ]
          }
        ],
        "volumes": [
          {
            "name": "persistent-storage",
            "persistentVolumeClaim": { "claimName": "ssb-artifacts-pvc" }
          }
        ]
      }
    }
  }
}'

Step 2.3 — Fix ownership on the volume (one-time)

The ssb-sse container runs as a non-root ssb user. A fresh hostPath volume comes up owned by root, and the UI upload will still fail on the first mkdir under /persistent/global/tmp/ even after the mount is there. Run a one-shot fixer pod:

kubectl run fix-perms --image=busybox --restart=Never -n cld-streaming --rm -it \
  --overrides='
{
  "spec": {
    "containers": [{
      "name": "fix-perms",
      "image": "busybox",
      "command": ["sh","-c","chmod -R 777 /mnt/persistent"],
      "volumeMounts": [{"name": "p", "mountPath": "/mnt/persistent"}]
    }],
    "volumes": [{"name": "p", "persistentVolumeClaim": {"claimName": "ssb-artifacts-pvc"}}]
  }
}'

777 is heavy-handed — on a shared cluster set fsGroup on the SSE pod’s securityContext instead and let the kubelet chgrp the volume on mount. For a demo cluster this is fine.

Step 2.4 — Test the upload

kubectl rollout restart deployment/ssb-sse -n cld-streaming
kubectl rollout status  deployment/ssb-sse -n cld-streaming --timeout=180s

SSB UI → Data Sources / Functions → upload the Iceberg connector JAR (or a custom UDF JAR). No Mkdirs failed error.

Confirm the bytes are actually on the PVC and not on ephemeral pod storage:

kubectl exec -n cld-streaming deploy/ssb-sse -- ls -la /persistent/
# and from the minikube VM (hostPath backing):
minikube ssh -- ls -la /data/ssb-persistent/

Step 2.5 — (Optional) Point SSB at the volume as its artifact store

Mounting is enough to make the upload path work, but SSB also has a “remote artifact storage” mode that publishes artifacts to a URI so Flink task managers can pull them without needing the same mount. For a single-cluster minikube demo, /persistent is enough. For anything real, use S3:

ssb:
  ssbConfiguration:
    application.properties: |+
      ssb.job-notifications.enabled=false
      ssb.sse.remote-artifact-storage-dir=sample-bucket/artifacts
      ssb.sse.remote-artifact-storage-type=s3
  storageConfiguration: |
    s3.access-key: root
    s3.secret-key: password
    s3.endpoint: http://minio:9000
    s3.path.style.access: true

storageConfiguration becomes a Secret mounted at /etc/hadoop-conf/artifact-storage inside both SSB and Flink pods. Put S3 credentials, endpoint overrides, path-style access, and anything else Flink’s s3 filesystem needs in there — never in the values file’s plain text.

Phase 3 — Persist Flink Checkpoints, Savepoints, and HA

The SSE side is now durable. The Flink jobs SSB runs are still not. If ssb-session-admin (the session cluster) restarts, or a FlinkSessionJob gets re-rolled, whatever keyed state that job had built up is gone unless there’s an externalized checkpoint pointing at durable storage.

Everything here goes into ssb.flinkConfiguration.flink-conf.yaml in csa-values.yaml. It’s appended to the default flink-conf and gets applied to every Flink job SSB deploys.

Option A — S3 (recommended for anything beyond a laptop demo)

ssb:
  flinkConfiguration:
    flink-conf.yaml: |+
      # SSB mounts Hadoop and Kerberos files manually
      kubernetes.decorator.hadoop-conf-mount.enabled: false
      kubernetes.decorator.kerberos-mount.enabled: false

      # State backend
      state.backend.type: rocksdb
      state.backend.incremental: true

      # Externalized checkpoints — survive job restart
      execution.checkpointing.interval: 60s
      execution.checkpointing.mode: EXACTLY_ONCE
      execution.checkpointing.externalized-checkpoint-retention: RETAIN_ON_CANCELLATION
      state.checkpoints.dir: s3://sample-bucket/checkpoints/
      state.savepoints.dir: s3://sample-bucket/savepoints/

      # High availability — survive JobManager restart
      high-availability.type: kubernetes
      high-availability.storageDir: s3://sample-bucket/ha/

Pair with the storageConfiguration block from Phase 2.5 so the s3:// scheme actually authenticates.

Option B — PVC (for a single-node minikube where you don’t want to run MinIO)

Flink can write checkpoints to any filesystem it can see. Mount a PVC into every Flink pod using the same podVolumes / podVolumeMounts mechanism from Phase 2, then point checkpoints at the mount path:

ssb:
  podVolumes:
    create: true
    data:
      - name: persistent-storage
        persistentVolumeClaim:
          claimName: ssb-artifacts-pvc
      - name: flink-state
        persistentVolumeClaim:
          claimName: flink-state-pvc      # RWX-capable StorageClass required
  podVolumeMounts:
    create: true
    data:
      - name: persistent-storage
        mountPath: /persistent
      - name: flink-state
        mountPath: /flink-state
  flinkConfiguration:
    flink-conf.yaml: |+
      state.backend.type: rocksdb
      state.backend.incremental: true
      execution.checkpointing.interval: 60s
      execution.checkpointing.externalized-checkpoint-retention: RETAIN_ON_CANCELLATION
      state.checkpoints.dir: file:///flink-state/checkpoints
      state.savepoints.dir: file:///flink-state/savepoints
      high-availability.type: kubernetes
      high-availability.storageDir: file:///flink-state/ha

The catch: RWO PVCs (which is what minikube’s standard StorageClass gives you) only bind to one node, so this only works if all Flink pods land on that node. For multi-node, you need RWX — Longhorn, NFS, or a cloud provider’s file-share class.

Option C — Ephemeral (default, do this if you’re fine losing state)

Do nothing. Checkpoints go to the local TaskManager working directory, HA is disabled, and a kubectl rollout restart on ssb-session-admin erases every running job’s state. Good enough for interactive SELECT * FROM … exploration; not good enough for any streaming pipeline you’d hand to someone else.

Full values file — put it all together

For copy-paste, this is a complete csa-values.yaml covering Phases 1–3 with S3:

flink-kubernetes-operator:
  enabled: true
  # clouderaLicense injected via --set-file at helm install time

ssb:
  enabled: true

  # Phase 1 — Postgres metadata
  database:
    create: true
    pvcSpec:
      accessModes: [ReadWriteOnce]
      resources:
        requests:
          storage: 5Gi
    resources:
      limits:   { cpu: "1", memory: "2048Mi" }
      requests: { cpu: "500m", memory: "1024Mi" }

  # Phase 2 — /persistent mount for uploads, applied to SSE + every Flink pod
  podVolumes:
    create: true
    data:
      - name: persistent-storage
        persistentVolumeClaim:
          claimName: ssb-artifacts-pvc
  podVolumeMounts:
    create: true
    data:
      - name: persistent-storage
        mountPath: /persistent

  # Phase 2.5 — S3 credentials for Flink's s3 filesystem, mounted as a Secret
  storageConfiguration: |
    s3.access-key: root
    s3.secret-key: password
    s3.endpoint: http://minio.cld-streaming.svc:9000
    s3.path.style.access: true

  # SSB tells Flink where to publish artifacts
  ssbConfiguration:
    application.properties: |+
      ssb.job-notifications.enabled=false
      ssb.sse.remote-artifact-storage-dir=sample-bucket/artifacts
      ssb.sse.remote-artifact-storage-type=s3

  # Phase 3 — Flink checkpoints, savepoints, HA
  flinkConfiguration:
    flink-conf.yaml: |+
      kubernetes.decorator.hadoop-conf-mount.enabled: false
      kubernetes.decorator.kerberos-mount.enabled: false

      state.backend.type: rocksdb
      state.backend.incremental: true

      execution.checkpointing.interval: 60s
      execution.checkpointing.mode: EXACTLY_ONCE
      execution.checkpointing.externalized-checkpoint-retention: RETAIN_ON_CANCELLATION
      state.checkpoints.dir: s3://sample-bucket/checkpoints/
      state.savepoints.dir: s3://sample-bucket/savepoints/

      high-availability.type: kubernetes
      high-availability.storageDir: s3://sample-bucket/ha/

Install (or upgrade):

helm upgrade --install csa-operator \
  --namespace cld-streaming \
  --version 1.5.0-b275 \
  -f csa-values.yaml \
  --set-file flink-kubernetes-operator.clouderaLicense.fileContent=./license.txt \
  --set 'flink-kubernetes-operator.imagePullSecrets[0].name=cloudera-creds' \
  --set 'ssb.sse.image.imagePullSecrets[0].name=cloudera-creds' \
  --set 'ssb.sqlRunner.image.imagePullSecrets[0].name=cloudera-creds' \
  --set 'ssb.mve.image.imagePullSecrets[0].name=cloudera-creds' \
  --set 'ssb.database.imagePullSecrets[0].name=cloudera-creds' \
  oci://container.repository.cloudera.com/cloudera-helm/csa-operator/csa-operator

The full persistence test

Deliberately break every pod in the CSA stack and confirm nothing disappears:

# 1. Baseline
kubectl exec -n cld-streaming deploy/ssb-postgresql -- \
  psql -U ssb_admin -c "SELECT count(*) FROM projects;"
kubectl exec -n cld-streaming deploy/ssb-sse -- ls -la /persistent/

# 2. Bounce everything
kubectl rollout restart deployment/ssb-postgresql -n cld-streaming
kubectl rollout restart deployment/ssb-sse        -n cld-streaming
kubectl rollout restart deployment/ssb-mve        -n cld-streaming
kubectl delete flinkdeployment ssb-session-admin  -n cld-streaming --wait=false
# operator re-creates ssb-session-admin from the ConfigMap

kubectl rollout status deployment/ssb-postgresql -n cld-streaming --timeout=180s
kubectl rollout status deployment/ssb-sse        -n cld-streaming --timeout=180s

# 3. Same numbers? Same files?
kubectl exec -n cld-streaming deploy/ssb-postgresql -- \
  psql -U ssb_admin -c "SELECT count(*) FROM projects;"
kubectl exec -n cld-streaming deploy/ssb-sse -- ls -la /persistent/

# 4. Running FlinkSessionJobs resumed from checkpoint?
kubectl get flinksessionjob -n cld-streaming
# LIFECYCLE STATE should still be STABLE, JOB STATUS RUNNING

If all four steps hold, you have real persistence.

Failure modes I’ve hit

Symptom Cause Fix
Mkdirs failed to create file:/persistent/global/tmp/... on JAR upload /persistent not mounted, or mounted but owned by root Phase 2.1 + 2.3
Upload works but the JAR is gone after rollout restart Mounted emptyDir instead of PVC (double-check the patch) Phase 2.2, verify with kubectl describe pod ssb-sse-... \| grep -A2 persistent-storage
Flink job in SSB fails with File does not exist: /persistent/... You patched the SSE pod only, not the Flink pods. podVolumes/podVolumeMounts covers both Move the mount into ssb.podVolumes in the values file, helm upgrade
s3:// checkpoint URLs fail with “No FileSystem for scheme” Missing storageConfiguration block, or missing S3 filesystem plugin in the Flink image Confirm flink-s3-fs-*.jar is in the image, and creds live in storageConfiguration
Postgres pod comes back but SSB UI shows no projects The PVC came back but the DB inside it wasn’t initialized — probably a fresh PVC that never had the schema written Re-run helm upgrade so the operator re-applies the postgres init ConfigMap
state.checkpoints.dir points at file:///flink-state/... and TaskManagers crashloop on multi-node RWO PVC only bindable to one node Use RWX StorageClass (Longhorn / NFS), or switch to S3

Reference

Everything in this post was validated against CSA Operator 1.5.0-b275 on minikube v1.37.0 / k8s v1.34.0. Chart values come straight from helm show values oci://container.repository.cloudera.com/cloudera-helm/csa-operator/csa-operator --version 1.5.0-b275, and the helm-value dictionary in the CSA docs Reference page.

Cloudera Streaming Analytics (CSA)

Companion persistence posts (same cld-streaming cluster)

The rest of the Cloudera Streaming Operators family (CSO)

Repos and images

  • Helm chart (OCI): oci://container.repository.cloudera.com/cloudera-helm/csa-operator/csa-operator
  • Container images (all 1.20.1-csaop1.5.0-b275 unless noted):
    • container.repository.cloudera.com/cloudera/flink-kubernetes-operator:1.13-csaop1.5.0-b275
    • container.repository.cloudera.com/cloudera/flink-extended:1.20.1-csaop1.5.0-b275
    • container.repository.cloudera.com/cloudera/ssb-sse:1.20.1-csaop1.5.0-b275
    • container.repository.cloudera.com/cloudera/ssb-mve:1.20.1-csaop1.5.0-b275
    • docker-private.infra.cloudera.com/cloudera_thirdparty/hardened/postgres:18.1-r0-openshift-202601250614
  • Sample YAMLs and helm values I use across the CSO stack: cldr-steven-matison/ClouderaStreamingOperators

Persistence with Cloudera Streaming Analytics Operator

If you would like a deeper dive, hands on experience, demos, or are interested in speaking with me further about Persistence with Cloudera Streaming Analytics Operator please reach out to schedule a discussion.

You may also enjoy
